Orion-Tr Smart Non-Isolated DC-DC Chargers

12/12V-30A (360W)

$215.05

Orion-Tr Smart Non-Isolated DC-DC Chargers

ORI121236140

The Victron Energy Orion-Tr Smart Non-Isolated DC-DC Charger is a versatile solution designed to charge auxiliary batteries or provide stable DC power in vehicle, marine, and off-grid systems. With a wide input and output voltage range, it ensures reliable and efficient charging performance across both 12V and 24V applications.

Featuring built-in Bluetooth®, the Orion-Tr Smart allows for easy monitoring, configuration, and programming through the VictronConnect app. It supports both lead-acid and lithium batteries and can be used as a battery charger or constant voltage power supply. Multiple units can be connected in parallel to increase output capacity, offering a flexible and scalable solution for high-demand power systems.

$215.05

Bluetooth Smart Enabled:

Any Bluetooth enabled smart phone, tablet or other device can be used to monitor, to change settings and to update the charger when new software features become available.
Instant Readout: The VictronConnect App can display key data, including warnings and alarms, on the Device list page without the need to connect to the product.

Fully Programmable:

Battery charge algorithm (configurable) or fixed output.
Smart alternator compatibility: engine running detection mechanism.

Adaptive 3-Stage Charge Algorithm: Bulk – Absorption – Float

For lead acid batteries it is important that during shallow discharges the absorption time is kept short in order to prevent overcharging of the battery. After a deep discharge the absorption time is automatically increased to make sure that the battery is completely recharged.
For lithium batteries absorption time is fixed, default 2 hours.
Alternatively, a fixed output voltage can be chosen.

Remote On/Off:

A remote on/off switch or relay contact can be connected to a two-pole connector.
Alternatively, the H terminal (right) of the two-pole connector can be switched to battery plus, or the L terminal (left) of the two pole connector can be switched to battery minus (or the chassis of a vehicle, for example).

All Models Are Short-Circuit Proof & Can Be Paralleled to Increase Output Current:

An unlimited number of units can be connected in parallel.

High Temperature Protected: The output current will reduce at high ambient temperature.IP43 Protection: When installed with the screw terminals oriented downwards.Screw Terminals: No special tools needed for installation.Input Fuse: Not replaceable
