Battle Born Elite 120W 12V Rigid Solar Panel

Battle Born Elite 120W 12V Rigid Solar Panel

Extra $200 OFF Orders of $1,999+
Extra $300 OFF Orders of $2,999+

Original price was: $149.00.Current price is: $139.99.

-

BBPV-12-120

The Battle Born® Elite 120W 12V Rigid Solar Panel brings high efficiency to compact installations. With 23% module efficiency and advanced anti-shading technology, it maintains strong output even in partial shade and low-light conditions. Built for longevity, this panel is tested against heavy snow, high winds, and salt mist exposure, ensuring dependable operation in challenging environments. Its smaller size makes it an excellent choice when roof space is limited but efficiency and durability are critical.

  • Higher Power Output in the Same Footprint: Advanced monocrystalline cells maximize watts per square inch
  • Anti-Shading Technology: Delivers reliable energy production even in partial shade or low-light conditions
  • 120W Power Delivery: Optimized for 12V systems
  • Compact & Lightweight: Measures 42.1 × 22.8 × 1.4 in, Weighs 15.7 lbs
  • Weather Tough: Rated for 5400 Pa snow load, 2400 Pa wind load, and salt mist resistance
  • Built to Last: Rigid anodized aluminum frame and low-iron tempered glass for structural strength and maximum light transmission
  • Proven Longevity: Backed by a 10-year workmanship warranty and 25-year linear performance warranty

Resources

Need Help?

Ask a technical specialist now at 855.292.2831

You Might Also Like

You may also like…

Product Features

Battle Born Elite 120W 12V Rigid Solar Panel
Battle Born Elite 120W 12V Rigid Solar Panel
Battle Born Elite 120W 12V Rigid Solar Panel
Battle Born Elite 120W 12V Rigid Solar Panel
Battle Born Elite 120W 12V Rigid Solar Panel
Battle Born Elite 120W 12V Rigid Solar Panel
Battle Born Elite 120W 12V Rigid Solar Panel

Features

  • Maximum Power (Pmax): 120W
  • Voltage at Pmax (Vmp): 19.08V
  • Current at Pmax (Imp): 6.30A
  • Open-Circuit Voltage (Voc): 22.35V
  • Short-Circuit Current (Isc): 6.70A
  • Temperature Coefficient of Voc: -(80±10)mV/°C
  • Temperature Coefficient of Isc: (0.065±0.015)%/°C
  • Temperature Coefficient of Power: -(0.5±0.05)%/°C
  • NOCT (Air 20°C; Sun 0.8kW/m² Wind 1m/s): 47±2°C
    • *NOCT: Nominal operating cell temperature (the data is only for reference)
  • Operating Temperature: -40°F to 185°F (-40°C to 85°C)
  • Maximum System Voltage: 1000V DC
  • Power Tolerance: ± 5%



Specifications

  • Cells: Monocrystalline Silicon Solar Cell
  • Number of Cells & Connections: 33 ( 3 x 11)
  • Module Dimension: 42.13” x 22.83” x 1.38”
  • Weight: 15.65 lbs.
  • Packing Information (Carton): 43.90” x 24.61“ x 2.76”
